Acer Notebook
Quick Guide
© 2010 All Rights Reserved.
Acer Notebook Quick Guide
Original Issue: 03/2010
Model number: __________________________________
Serial number: ___________________________________
Date of purchase: ________________________________
Place of purchase: ________________________________
3
First things first
We would like to thank you for making an Acer notebook your choice for
meeting your mobile computing needs.
Your guides
To help you use your Acer notebook, we have designed a set of guides:
First off, the Ju
st for Starters... poster helps you get started with setting up your
computer.
The As
pire Series Generic User Guide contains useful information applying to all
models in the Aspire product series. It covers basic topics such as using the
keyboard and audio, etc. Please understand that due to its nature, the Generic
User Guide as well as the AcerSystem User Guide mentioned below will
occasionally refer to functions or features which are only contained in certain
models of the series, but not necessarily in the model you purchased. Such
instances are marked in the text with language such as "only for certain
models".
The Quick Gu
ide introduces you to the basic features and functions of your new
computer. For more on how your computer can help you to be more productive,
please refer to the AcerSystem User Guide. This guide contains detailed
information on such subjects as system utilities, data recovery, expansion
options and troubleshooting. In addition it contains warranty information and
the general regulations and safety notices for your notebook. It is available in
Portable Document Format (PDF) and comes preloaded on your notebook.
Follow these steps to access it:
1 Click on
Start > All Programs > AcerSystem.
2 Click on AcerSystem
User Guide.
Note: Viewing the file requires Adobe Reader. If Adobe Reader is not
installed on your computer, clicking on AcerSystem User Guide will run the
Adobe Reader setup program first. Follow the instructions on the screen to
complete the installation. For instructions on how to use Adobe Reader,
access the Help and Support menu.
4
Your Acer notebook tour
After setting up your computer as illustrated in the Just for Starters... poster, let
English
us show you around your new Acer notebook.
Top view
1
2
3
13
12
4
5
11
6
10
7
8
9
# Icon Item Description
1 Acer Crystal Eye
Web camera for video communication.
webca
m
(only for certain models)
2 Display screen Also called Liquid-Crystal Display (LCD),
displa
ys computer output (configuration
may vary by models).
5
English
# Icon Item Description
3 Arcade key Launches InstantOn Arcade.
P P key / Acer
Programmable key (configuration may
PowerSmart key
vary b
y model). / Puts your computer into
power-saving mode (configuration may
vary by model).
4 Keyboard For entering data into your computer.
5 Microphone Internal microphone for sound recording.
6
Touchpad / Media
Touch-sensitive pointing device which
Console
*
functions like a computer mouse
. / Touch
sensitive controls for Acer Arcade, volume
(up/down) and media (play/pause, stop,
previous, next); with mute.
Movie Launch movie
playbac
k software.
Music Launch music
playback software.
Play/pause Play or pause a
selected media file.
Stop Stop playing the
selected media file.
Previous Return to the
previous media file.
Next Jump to the next
media file.
Mute Turn the volume on
or off.
* Touchpad becomes inactive when
Media Console is active.
7 Media Console
Turns Media Console on or off.
con
troller
8
Communication
Enables/disables the computer’s
key
communication devices. (Communication
devices may vary by configuration.)
Backup key Launches Acer Backup Management for
three-step data backup.
1
Indicates when the hard disk drive is
HDD indicator
active.
1
Indicates the computer’s power status.
Power indicator
6
# Icon Item Description
9 Click buttons (left
The left and right buttons function like
and right)
the left and right mouse buttons.
English
10 Palmrest Comfortable support area for your hands
when yo
u use the computer.
11 Acer Bio-
Supports Acer FingerNav 4-way control
Protection
function (only for certain models).
finge
rprint reader
12 Speakers Deliver stereo audio output.
13
Power button Turns the computer on and off.
1. The front panel indicators are visible even when the computer cover is closed
up.
Hotkeys
The computer employs hotkeys or key combinations to access most of the
computer's controls like screen brightness and volume output.
To activate hotkeys, press and hold the <
F
n> key before pressing the other key
in the hotkey combination.
Hotkey Icon Function Description
<Fn> + <F3>
C
ommunication
Enables/disables the computer’s
key
comm
unication devices.
(Communication devices may vary by
configuration.)
<Fn> + <F4>
Sleep Puts the
computer in Sleep mode.
<Fn> + <F5> Display toggle Switches display output between the
display
screen, external monitor (if
connected) and both.
<Fn> + <F6> Screen blank Turns the display screen backlight off
to save power. Press any key to
return.
<Fn> + <F7>
To
uchpad
Turns the internal touchpad on and
toggle
off.
<Fn> + <F8>
Speake
r toggle Turns the speakers on and off.
<Fn> + <
>
Br
ightness up Increases the screen brightness.
7
English
Hotkey Icon Function Description
<Fn> + <
>
Brightness
Decreases the screen brightness.
down
<Fn> +
Play/Pause Play or pause a selected media file.
<Home
>
<Fn> +
Stop Stop playing the selected media file.
<Pg Up>
<Fn> +
Previous Return to the previous media file.
<Pg Dn>
<Fn> +
Next Jump to the next media file.
<End>
Closed front view
123
# Icon Item Description
1 Thumbwheel Turn the volume up or down.
2
Multi-in-1 card reader Accepts Secure Digital (SD),
MultiMediaCard (MMC), Memory
Stick (MS), Memory Stick PRO (MS
PRO), xD-Picture Card (xD).
Note: P
ush to remove/install the
card. Only one card can operate at
any given time.
3 CIR receiver Receives signals from a remote
control.
8
Rear view
English
1
# Icon Item Description
1
Battery bay Houses the computer's battery pack.
Left view
21345687
# Icon Item Description
1
Kensington lock slot Connects to a Kensington-
compatible computer security lock.
Note: W
rap the computer security
lock cable around an immovable
object such as a table or handle of a
locked drawer. Insert the lock into
the notch and turn the key to
secure the lock. Some keyless
models are also available.
2 Ventilation slots Enable the computer to stay cool,
ev
en after prolonged use.
3
External display
Connects to a display device (e.g.,
(VGA) port
external monitor, LCD projector).
4 HDMI HDMI port Supports high definition digital
vi
deo connections.
5
USB 2.0 / e SATA port Connects to USB 2.0 or eSATA
devices (only for certain models).
Note: If you
plug an eSATA device
you will have three USB ports
available in the meantime.
9
English
# Icon Item Description
6 USB 2.0 port Connects to USB 2.0 devices (e.g.,
USB mouse, USB camera).
7
4-pin IEEE 1394 port Connects to IEEE 1394 devices.
8
Line-in jack Accepts audio line-in devices (e.g.,
audio CD player, stereo walkman,
mp3 player)
Microphone-in jack Accepts inputs from external
microphones.
Headphones/speaker/
Connects to audio line-out devices
line-out jack with
(e.g., speakers, headphones).
S/PDIF support
Right view
2135678
4
# Icon Item Description
1
USB 2.0 ports Connect to USB 2.0 devices
(e.g., USB mouse, USB camera).
2 Optical drive Internal optical drive; accepts CDs or
DVDs.
3 Optical disk access
Lights up when the optical drive is
in
dicator
active.
4 Optical drive eject
Ejects the optical disk from the drive.
button
5 Emergency eject
Ejects the optical drive tray when the
ho
le
computer is turned off.
Note: I
nsert a paper clip to the
emergency eject hole to eject the
optical drive tray when the computer
is off.
6
Ethernet (RJ-45)
Connects to an Ethernet 10/100/1000-
port
based network.
10
# Icon Item Description
7
RF-in port Accepts input signals from digital TV-
tuner devices.
English
(only for certain models)
8
DC-in jack Connects to an AC adapter.
Base view
1
8
2
3
4
7
5
6
# Icon Item Description
1
Battery bay Houses the computer's battery pack.
2 Sub woofer Emits low frequency sound output.
3
Battery release latch Releases the battery for removal.
4
Memory compartment Houses the computer's main memory.
5
Hard disk bay-Main Houses the computer's hard disk (secured
with screws).
6 Speakers Deliver stereo audio output.
7
Hard disk bay-
Houses the computer's hard disk (secured
Secondary
with screws) (for certain models only).
8
Battery lock Locks the battery in position.
11
English
Environment
• Temperature:
• Operating: 5 °C to 35 °C
• Non-operating: -20 °C to 65 °C
• Humidity (non-condensing):
• Operating: 20% to 80%
• Non-operating: 20% to 80%
